18t Airport Pallet Dolly Aviation Container Transport Dolly

📋

Basic Information

Model NO.

APD

ABS

Without ABS

Tire Number

4

Color

Optional

Condition

New

Origin

China

Capacity

500 Pieces Per Month

⚙️

Product Description

Main Function: Designed for the efficient transportation of P1P, P6P, LD1, and LD2 aviation containers.

📊

Product Specifications

SPECIFICATION OF PALLET DOLLY
Load Orientation	Side/rear	Max Payload (kg)	1600 / 7000 / 18000 / 27000
Tare (Kg)	1103 / 1450 / 1352	Wheel Base (mm)	1600 / 2060
Overall Dim (mm)	4109(L) * 3400(W) * 1563(H)	Platform Height (mm)	508-518
Towbar Height (mm)	606-625	Length Between Tyres (mm)	1960-2484
Wheels (mm)	400*100 (Front & Rear)	Roller Dia (mm)	76
Max Speed (Km/h)	25	Min Turn Radius (mm)	<=4500

🌟

Product Features

✔ Solid cushion tyres for long service life.
✔ Stoppers at both ends for side guides & positive locking.
✔ Tow hitch at rear end for multi-dolly linkage.
✔ Galvanized rollers with chequered plate walkways.
✔ Tow bar integrated with multi-dolly linkage and brake functions.
✔ Fork tynes on both sides to support forklift handling.
✔ Powered brush or blast finish with optional custom paint.
✔ Unit ID number pad available upon request.

📸

Detailed Photos

❓

Frequently Asked Questions

1. What types of aviation containers is this dolly compatible with?

The pallet dolly is specifically designed to transport P1P, P6P, LD1, and LD2 containers efficiently within airport environments.

2. What is the maximum payload capacity available?

We offer various configurations with payload capacities ranging from 1,600kg up to 27,000kg to meet different operational requirements.

3. Does the dolly include safety braking features?

Yes, the tow bar is designed with integrated brake functions that activate to ensure safety during linkage and stationary positions.

4. Can multiple dollies be connected for transport?

Yes, the units feature a rear tow hitch and a specialized tow bar to allow for multi-dolly linkage, enabling a train-like transport system.

5. Is the equipment suitable for forklift handling?

Absolutely. The design includes fork tynes on both sides, making it easy for forklifts to maneuver or reposition the dolly when needed.

6. What makes your pallet dollies durable for long-term use?

Our dollies utilize solid cushion tyres, galvanized rollers, and a strict quality control manufacturing process to ensure reliability in high-traffic cargo environments.
